30 mm PUF Sandwich Roof Panel

Price 1250.0 INR/ Square Foot

Get a Price/Quote

30 mm PUF Sandwich Roof Panel Specification

Usage & Applications
PUF Sandwich Roof Panel

Features
Water Proof

Type
Roofing Sheets / Panels

Size
30 mm

Shape
Different Available

Pattern
Plain

Thickness
0.5 To 3 Millimeter (mm)

30 mm PUF Sandwich Roof Panel Trade Information

Minimum Order Quantity
1000 Square Foot

Supply Ability
5000 Per Month

Delivery Time
Days

Main Domestic Market
West India

About 30 mm PUF Sandwich Roof Panel

Phoenixx Sandwich PUF Panel Technical Specification

Brand:Phoenixx
Product:Sandwich PUF Panel (Wall / Ceiling / Roofing)

1. General Description

Phoenixx Sandwich PUF Panels are energy-efficient, pre-fabricated insulated panels designed for walls, ceilings, and roofing. These panels consist of a high-density Polyurethane Foam (PUF) core sandwiched between two rigid metal sheets, ensuring superior thermal insulation, durability, and environmental resistance.

2. Technical Specifications

Parameter	Specification
Thickness	30mm, 40mm, 50mm, 60mm, 80mm, 100mm
Width	Standard: 1000mm
Length	Customizable as per site requirements
Core Material	Rigid Polyurethane Foam (PUF)
PUF Density	40 2 kg/m
Thermal Conductivity	0.023 W/mK
Fire Rating	Class 1 (BS 476 Part 7) / FM Approved
Compressive Strength	200 kPa
Water Absorption	2% (By volume)
Temperature Range	-40C to +80C
Sound Insulation	Up to 30 dB Reduction

3. Facing Sheet Options

Material	Coating	Thickness
PPGI / PPGL	Polyester / PVDF / SMP	0.4mm 0.8mm
Stainless Steel (SS 304/316)	BA/Matte Finish	0.5mm 1.0mm
Aluminum (Embossed/Plain)	PVDF/Polyester	0.5mm 1.0mm

4. Joint System

Camlock, Tongue & Groove, or Overlap Jointing for seamless installation
Leakproof, airtight, ensuring enhanced thermal efficiency

5. Features & Benefits

High Thermal Insulation Reduces heat transfer & energy costs
Lightweight & Easy Installation Quick & cost-effective
Fire Resistance Class 1 fire-rated for safety
Durable & Long-Lasting Withstands harsh environments
Water & Moisture Resistant Prevents fungal/bacterial growth
Aesthetic Appeal Clean, smooth surface finish
Low Maintenance Long lifespan with minimal upkeep

6. Applications

Cold Storage Walls, Ceilings & Roofing
Cleanroom & Pharmaceutical Units
Food Processing & Dairy Facilities
Modular Prefabricated Buildings
Industrial & Commercial Structures
HVAC Ducting Enclosures

7. Compliance & Certifications

ISO 9001:2015 Certified
FM Approved (Fire Safe) Options
CE Marking for Quality Assurance
Compliant with IS & ASTM Standards

For inquiries, contactPhoenixx Infratech Projectstoday!

Superior Insulation and Waterproof Construction

Our PUF Sandwich Roof Panels feature a 30 mm thick insulated core, providing outstanding thermal efficiency and robust waterproofing. These panels are ideal for protecting your facility from extreme weather, minimizing heat transfer, and reducing energy consumption. Their high durability ensures long-lasting performance even in demanding environments.

Versatile Application for Modern Architecture

With a choice of thickness from 0.5 to 3 mm and various shapes available, these panels can be seamlessly integrated into diverse architectural designs. Whether for factories, warehouses, or modern homes, the panels offer a sleek, plain finish and simplify installation while enhancing structural strength.

FAQs of 30 mm PUF Sandwich Roof Panel:

Q: How are 30 mm PUF Sandwich Roof Panels installed?

A: The installation process involves fixing the panels onto a structural framework using appropriate fasteners and sealants. Professional installers ensure that the PUF core is properly aligned and tightly secured for maximum insulation and waterproofing.

Q: What advantages do PUF Sandwich Roof Panels offer over traditional roofing sheets?

A: PUF Sandwich Roof Panels provide superior thermal insulation, are lightweight, easy to install, and deliver excellent waterproofing versus conventional roofing. This results in lower energy costs and longer service life for buildings.

Q: When should I consider using PUF Sandwich Roof Panels?

A: Consider these panels when constructing or renovating industrial, commercial, or residential buildings where energy efficiency, waterproofing, and quick installation are priorities.

Q: Where can these PUF panels be applied?

A: These panels can be used for roofs in factories, warehouses, cold storages, homes, and institutional buildings, thanks to their adaptability and insulation properties.

Q: What is the manufacturing process for these sandwich panels?

A: PUF cores are sandwiched between two metal sheets, then compressed and bonded together under high pressure, resulting in durable, uniform panels with consistent thermal properties.

Q: How does the thickness influence the performance of the roof panel?

A: Thicker panels generally offer enhanced insulation and greater structural strength. Choose the appropriate thickness based on climate and load-bearing requirements for optimal results.
